To catch a sweet ride, surfers rely heavily on two things: the waves, and their board.
Surfers can order surfboards that are customised to their needs, or choose from a range of pre-made boards, with little difference in cost. When it comes to surfboard fins, however, it’s a different story.
Fins are aerodynamic foils that act like rudders while surfing, usually attached to the rear bottom of the surfboard. Fins were once permanently glassed into the board, but these days almost all boards have a removable fin system.
Manufacturers of removable fin systems make exceptional products, but the current manufacturing process involves injection moulding, which is very expensive. This pushes it out of economic reach for most surfers looking for a customised fin.
Enter three dimensional (3D) printing. We have developed, designed and 3D printed surfboard fins made from composite materials, and have built and trialled prototype fins with flexibility similar to those available in shops.
3D printed surfing fins
3D printing (or additive manufacturing) refers to a range of manufacturing technologies using computer-aided design and layer-by-layer, bottom-up construction.
Bypassing the need for conventional technologies – such as milling, turning or moulding – it’s perfect for rapid prototyping and fabrication of custom-designed products. 3D printing is ideal for building surfing fins.
Although using 3D printing to make fins is relatively new, there are several examples available on the internet. Most of these have been produced on FDM (Fused Deposition Modelling) printers.
The market for fins
Fins never used to be disposable, at least not for most recreational surfers. These days, however, almost every surfboard (either custom made or bought from a shop) is sold without fins. The fins have become a separate commodity that surfers add to their surfboard. Many surfers use different fins on the same board depending on the wave conditions, such as stiffer fins for larger waves.
The surf retail scene has changed accordingly. Shops have sprung up that are now entirely dedicated to just selling fins.
Fin prices vary depending on the type of surfboard. High-end single fins for longboards and stand-up paddle boards retail for up to AU$150. For shortboards fitted with a thruster (three fin) configuration, prices vary between AU$50 and AU$180.
Surfers wanting the option of surfing their board in either thruster or quad (four fin) configurations can pay as much as AU$270 for a complimentary set of five fins.
Data on fin sales are not easy to find, but the annual revenue for the entire surfing industry is estimated at US$ 7.3 billion. And given that the number of Australians who surf is at least 750,000, the Australian market for fins is around A$75 million per year (based on the conservative assumption that every year each Australian surfer buys at least one set of fins, worth A$100).
Traditional fin production
Mass produced fins all use some sort of moulding process that involves injecting resin in combination with materials such as fibreglass.
Other options include using a honeycomb or hexagonal core that is incorporated in the moulding process. This can be further modified by strategically placing a skin of carbon, Kevlar or aluminium-coated fibreglass (texalium) on the fin during production. Commercial fins are usually composite materials.
However, the key is to use materials that offer the required material characteristics, such as stiffness or flexibility. We have found that composite, or mixed materials are required to produce 3D printed fins with similar flex properties to that found in commercial fins.
What surfers look for in fins
Fins in surfboards enable surfers to control the direction that their surfboard travels.
The physics of this takes time to explain, but it essentially comes down to this: surfers look for a surfboard and fin combination that enables them to execute manoeuvres with speed, power and/or flow depending on their skill level.
3D printing allows a surfer to tailor-make a fin suited to their particular style of surfing. Just like paying for a set of golf clubs fitted to your size and skill level, 3D printing enables the fitting of fins to your surfboard, height, weight, ability and style.
In addition, surfers are thinking more and more about sustainable solutions for the surfing industry. 3D printers can easily incorporate recycled materials to print new fins.
Ready-made vs custom-built
There are surfers who like to buy ready-made boards, and those who order custom boards from shapers. With fins, this is likely to be similar.
3D printed fins are for those surfers who like to control all aspects of their surfing equipment, and will suit those who feel it is important to have fins made to their exact specification.
3D printed fins also offer advantages for developing personalised fins for surf therapy and adaptive (disabled) surfer programs, depending on the needs of the surfer. Personalised fins will allow for better stability, control and steering thereby enhancing the surfing experience.
3D printing may even change surfboard construction. Recently, three-time world surfing champion Mick Fanning rode waves using a 3D-printed surfboard. While most of us won’t achieve the lofty heights of Australia’s champion professional surfer, there may soon be a day when every surfer will be able to insert custom made 3D printed fins into a board, and take to the waves.
Lead author Marc in het Panhuis gets up every day before sunrise, and heads to the ocean for a surf.
